RG-TEV8240
Battery Pack
70kwh LFP Battery Pack
Hopper Capacity
1850L
Sweeping Width
1600-2400MM
Kerb Weight
2700KG
特点
Solar charging is available. The 70kWh battery pack is designed to provide 11-13 hours of working time. The road sweeper is equipped with a touch screen, a control panel, and a one-key operation button, along with functions including heating and cooling air conditioning, high-pressure flushing, and sewage discharge from the garbage bin. Replaceable front-end attachments enable multi-purpose use, which can meet the operation needs in snowy weather.
Rated Load
5800kg
Rated Load
5800kg
Rated Load
5800kg
Consultation:
Keywords:
RG-TEV8240
Email:
- Performance
-
- Commodity name: RG-TEV8240
- Battery Pack: 70kwh LFP Battery Pack
- Hopper Capacity: 1850L
- Sweeping Width: 1600-2400MM
- Kerb Weight: 2700KG
- 特点: Solar charging is available. The 70kWh battery pack is designed to provide 11-13 hours of working time. The road sweeper is equipped with a touch screen, a control panel, and a one-key operation button, along with functions including heating and cooling air conditioning, high-pressure flushing, and sewage discharge from the garbage bin. Replaceable front-end attachments enable multi-purpose use, which can meet the operation needs in snowy weather.
<ul><li><span>Battery</span>70kwh LFP Battery Pack</li> <li><span>Hopper Capacity</span> 1850L</li> <li><span>Sweeping Width</span>1600-2400MM</li></ul>
Solar Lithium-ion Sweeper RG-TEV8240
Solar lithium-ion sweepers are eco-friendly and high-efficiency cleaning equipment, specifically designed for outdoor cleaning tasks. Equipped with high-performance lithium batteries and supplemented by solar panels for power supply, they provide zero-emission, low-noise green cleaning solutions suitable for urban streets, parks, factories, and large commercial areas.
Advantages
Solar Power Supply: Equipped with high-efficiency solar panels to extend single-charge operation time, reduce reliance on traditional electricity, and achieve green, eco-friendly cleaning operations.
Intelligent Battery Life Management: Built-in 70kWh large-capacity lithium battery, featuring fast charging speed, long service life, long cycle life, and light weight.
High-Efficiency Cleaning Performance: Equipped with a powerful vacuum and sweeping system, capable of effectively cleaning various types of debris.Low-Noise Design: Operates with low noise, suitable for areas with high pedestrian flow or noise-sensitive environments.
Durable Structure: Made of high-strength materials, with dustproof and waterproof performance, capable of withstanding various harsh working environments.
Product Specifications
- Dimensions: 4310*1280*2150mm
- Weight: 2700kg
- Battery Capacity: 307V/230Ah/70kWh
- Operation Time: 11 hours
- Solar Panel Power: 1200W
- Hopper Capacity: 1850L
- Cleaning Width: 1.6-2.4m
- Working Speed: 5-12km/h
- Dumping Height: 1580mm
Applicable Scenarios
Municipal Sanitation: Used for daily cleaning of sidewalks and narrow back streets, making up for the limitation that large sweepers cannot access narrow roads.
Residential Properties: Cleans residential roads, parking lots, and areas around green belts. Its low-noise design avoids disturbing residents' rest.
Scenic Areas/Parks: Cleans trails, squares, and other areas. Its zero-emission feature meets the ecological and environmental protection requirements of scenic areas.
Industrial Parks: Cleans areas around workshops and warehouse passages. Its compact body can flexibly navigate through gaps between equipment.
Configuration
1. Solar-Assisted Charging System
Equipped with a 1.2kWh high-efficiency monocrystalline silicon solar panel, which generates approximately 1-2 kWh of electricity per day under sufficient sunlight to extend single-charge operation time. It also supports fast charging via municipal power, allowing a full charge in 2-3 hours, solving the problem of insufficient solar power supply on cloudy or rainy days.2. High-Efficiency Cleaning Brushes
The sweeping brushes are durable standard steel wire-nylon composite brushes, renowned for their excellent wear resistance. They feature independent on/off control, and their height and width can be adjusted to meet diverse cleaning needs. In addition, the rotation speed is continuously variable and equipped with an obstacle avoidance function to improve efficiency and safety. Adopting a combined sweeping and suction structure, the brushes can fit closely to curbside gaps, achieving a maximum cleaning width of 2.4m. They deeply clean road debris such as dust, fallen leaves, and small stones, and are suitable for small-scale scenarios like sidewalks, residential roads, and scenic trails, with a cleaning area of approximately 24,400 square meters per hour.
3. Intelligent Battery Life Management
Built with a 70kWh large-capacity lithium battery, it can achieve up to 10 hours of operation in pure electric mode, meeting the demand for all-day work. In solar-assisted mode, the operation time can be extended by an additional 1-2 hours, reducing the frequency of mid-operation charging and improving daily work efficiency.4. User-Friendly Operation & Safety Design
Equipped with a panoramic glass driving cab, heating and cooling air conditioning, shock-absorbing seats, front and rear dashcams, a touch display screen, and a simple operation panel. The body is also fitted with an emergency stop button to ensure the safety of personnel and equipment during operation.
